Cleagow MC4

Versatile. That characterizes this Multi Carrier MC4. Whether it's cleaning a festival site, campsite, fairground, parking lot, roadside verge, or city park.

Various configurations
Agile on any terrain
Lightweight
Excellent driving comfort
Quick-change system

A total solution

Fast, powerful, and efficient

The Cleagow MC4 Multi Carrier is designed and built for rough terrain and performs under the toughest conditions. An ideal and indispensable machine for companies and municipalities looking for a complete solution for recurring tasks. Fast, powerful, and efficient.

Application

The universal tool carrier can be used anywhere. Thanks to its lightweight and extreme manoeuvrability, you don’t need to worry about the condition of the terrain, regardless of the surface or the type of work.

Afbeelding
Afbeelding

Manoeuvrability

The 4-wheel steering system makes the machine extremely manoeuvrable, allowing it to reach even the most difficult places. Thanks to the small turning radius, the Cleagow easily navigates through tight spaces.

The operator can select different steering modes depending on the desired situation:

  • Road Mode (front axle only)

  • Auto Mode (automatic activation of rear axle steering based on driving speed)

  • Manual Mode (independent control of the rear axle)

Cooling System

Convenience is key. That’s why the radiator is automatically cleaned through a built-in cleaning system, preventing the engine from overheating. This can be done fully automatically according to a schedule or additionally by a command from the operator. For instance, in extra demanding or hot (weather) conditions.

Afbeelding
Afbeelding

Auto-Diagnostic System

To ensure the MC4 Multi Carrier can be deployed smoothly every day, the cabin is equipped with an intuitive user interface. This auto-diagnostic system provides a clear overview of the machine’s status.

Service

Thanks to its easy maintenance, the Cleagow MC4 Multi Carrier always performs optimally under all conditions. A daily maintenance task is cleaning the air filter and checking the oil level. That's why we’ve made sure these components are easy to access. Ready for the next job!

Afbeelding

Request the catalog.
No time to waste!

Product specifications

General

ENGINE
Deutz TD2.9L4 Stage V (55.4 kW / 75 hp)
UNDERCARRIAGE SYSTEM
Stepless hydrostatic 4-wheel drive, 2-speed, lock F/A
STEERING SYSTEM
4-wheel steer, track-following, independent front and rear
BRAKE SYSTEM
Dynamic 4-wheel hydraulic disc brakes, dual circuit
PARKING BRAKE
Rear wheels
OPERATING SYSTEM
12V Widontec control system incl. 4.3” color display
SPEED (ROAD)
40 km/h
SPEED (WORK)
20 km/h

Hydraulic

HYDRAULIC SYSTEM 1
20 l/min @ 180 bar; 2 dw valves rear
HYDRAULIC SYSTEM 2
94 l/m@350bar; prop. A-B
POWER FOR EXTENSION TOOL
45 kW

Wheels en chassis

WHEELBASE STANDARD (LXW)
2370 x 1260 mm
TIRE SIZE STANDARD
340 / 55 R16 Trelleborg profile AW309 (grass tyre)
CHASSIS LOAD CAPACITY
2.300 kg
WEIGHT EMPTY EXCLUDING EXTENSION
1.700 kg
TURNING RADIUS
3,9 m

Additional documents: user manual / parts book
